Kamov

Manufacturer:

Kamov

Country:

Russia

Commercial designation:

Ka-32

Technical designation:

Ka-32

Version, Variant:

A11BC

Type:

Contra

Currently produced:

Y

Typical missions:

Civil Agriculture Firefight Law Rescue Transport Utility Offshore

Flight conditions:

IFR

First flight:

1999

Landing system:

wheels

Blades number:

6

Tail blades number:

0

MTOW with external loads:

12700 kg

28003.5 lbs

MTOW with only internal loading:

11000 kg

24255 lbs

Empty weight:

6610 kg

14575.05 lbs

External payload:

5000 kg

11025 lbs

Internal payload:

3700 kg

8158.5 lbs

Standard fuel tank:

1744 kg

3845.52 lbs

with optionnal external fuel tank:

4504 kg

9931.32 lbs

Cruise speed:

230 km/h

124.2 kt

Maximum cruise speed:

245 km/h

132.3 kt

Vne:

260 km/h

140.4 kt

Max negative g @ MTOW:

0 g

Max positive g @ MTOW:

0 g

Range with normal tanks:

800 km

432 nm

Max range with auxiliary external tanks:

1135 km

612.9 nm

Max endurance @ min consumption speed:

04:30:00 h:min

Rate of climb @ SL:

0 m/s

0 ft/min

Rate of climb @ SL @MTOW:

0 m/s

0 ft/min

IGE max hovering altitude, MTOW:

3000 m

9840 ft

IGE max hovering altitude, empty:

0 m

0 ft

IGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

IGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

OGE max hovering altitude, MTOW:

3500 m

11480 ft

OGE max hovering altitude, empty:

0 m

0 ft

OGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

OGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

Service ceiling ISA, MTOW:

5000 m

16400 ft

Max operating altitude, empty weight:

5000 m

16400 ft

Highest use Temperature:

0 °C

0 °F

Lowest use Temperature:

0 °C

0 °F

APU in HC:

Engine manufacturer:

Motor Sich

Model:

TV3-117VMA

Engines quantity:

2

Powerplant category:

turbine

Main rotor rotation speed:

0 rpm

Fuel consumption @ SL @ max continuous speed:

0 kg/kW/h

0 lbs/hp/h

Minimum consumption speed @ SL:

0 km/h

0 kt

Fuel consumption @ eco cruise speed @SL:

0 kg/h

0 lbs/h

Fuel consumption @ min consumption speed @ SL:

0 kg/h

0 lbs/h

Engines nominal power:

3270 kW

4443.93 hp

Transmission shaft max continuous power:

0 kW

0 hp

Transmission shaft max power:

0 kW

0 hp

Takeoff power 5 min:

3270 kW

4443.93 hp

OEI 30s power:

1790 kW

2432.61 hp

OEI 2min power:

0 kW

0 hp

OEI max continuous power :

0 kW

0 hp

OEI max continuous transmission power:

0 kW

0 hp

OEI 30 sec transmission power:

0 kW

0 hp

OEI 2 min transmission power:

0 kW

0 hp

Overall length:

15.9 m

52.152 ft

Rotor diameter:

15.9 m

52.152 ft

Tail rotor diameter:

0 m

0 ft

Fuselage length:

11.3 m

37.064 ft

Overall height:

5.4 m

17.712 ft

Main rotor blades chord:

0 m

0 ft

Tail rotor blades chord:

0 m

0 ft

Mast tilt angle:

0 °

Noise at flyover, level:

99 dB EPNL

Noise at flyover, limit:

99 dB EPNL

Noise at takeoff, level:

100 dB EPNL

Noise at takeoff, limit:

100 dB EPNL

Noise at landing, level:

101 dB EPNL

Noise at landing, limit:

101 dB EPNL

Crew:

2

Max pax number:

13

Average price:

0 $
