Boeing

Manufacturer:

Boeing

Country:

USA

Commercial designation:

Apache

Technical designation:

AH-64

Version, Variant:

A

Type:

Conventional

Currently produced:

N

Typical missions:

Military Combat Attack

Flight conditions:

IFR

First flight:

1975

Landing system:

wheels

Blades number:

0

Tail blades number:

0

MTOW with external loads:

10433 kg

23004.765 lbs

MTOW with only internal loading:

10433 kg

23004.765 lbs

Empty weight:

5165 kg

11388.825 lbs

External payload:

0 kg

0 lbs

Internal payload:

0 kg

0 lbs

Standard fuel tank:

1137 kg

2507.085 lbs

with optionnal external fuel tank:

3925 kg

8654.625 lbs

Cruise speed:

0 km/h

0 kt

Maximum cruise speed:

293 km/h

158.22 kt

Vne:

364 km/h

196.56 kt

Max negative g @ MTOW:

-0.5 g

Max positive g @ MTOW:

3.5 g

Range with normal tanks:

562 km

303.48 nm

Max range with auxiliary external tanks:

1896 km

1023.84 nm

Max endurance @ min consumption speed:

02:30:00 h:min

Rate of climb @ SL:

12.7 m/s

2499.36 ft/min

Rate of climb @ SL @MTOW:

5.2 m/s

1023.36 ft/min

IGE max hovering altitude, MTOW:

0 m

0 ft

IGE max hovering altitude, empty:

4570 m

14989.6 ft

IGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

IGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

OGE max hovering altitude, MTOW:

0 m

0 ft

OGE max hovering altitude, empty:

3505 m

11496.4 ft

OGE max hovering altitude, ISA+20°C, MTOW:

0 m

0 ft

OGE max hovering altitude, ISA+20°C, empty:

0 m

0 ft

Service ceiling ISA, MTOW:

0 m

0 ft

Max operating altitude, empty weight:

6400 m

20992 ft

Highest use Temperature:

0 °C

0 °F

Lowest use Temperature:

0 °C

0 °F

APU in HC:

Y

Engine manufacturer:

General Electric

Model:

T700-GE-701C

Engines quantity:

2

Powerplant category:

turbine

Main rotor rotation speed:

0 rpm

Fuel consumption @ SL @ max continuous speed:

0 kg/kW/h

0 lbs/hp/h

Minimum consumption speed @ SL:

0 km/h

0 kt

Fuel consumption @ eco cruise speed @SL:

0 kg/h

0 lbs/h

Fuel consumption @ min consumption speed @ SL:

0 kg/h

0 lbs/h

Engines nominal power:

2476 kW

3364.884 hp

Transmission shaft max continuous power:

0 kW

0 hp

Transmission shaft max power:

0 kW

0 hp

Takeoff power 5 min:

2820 kW

3832.38 hp

OEI 30s power:

0 kW

0 hp

OEI 2min power:

0 kW

0 hp

OEI max continuous power :

0 kW

0 hp

OEI max continuous transmission power:

0 kW

0 hp

OEI 30 sec transmission power:

0 kW

0 hp

OEI 2 min transmission power:

1447 kW

1966.473 hp

Overall length:

17.61 m

57.7608 ft

Rotor diameter:

14.48 m

47.4944 ft

Tail rotor diameter:

2.79 m

9.1512 ft

Fuselage length:

15.54 m

50.9712 ft

Overall height:

4.66 m

15.2848 ft

Main rotor blades chord:

0.53 m

1.7384 ft

Tail rotor blades chord:

0 m

0 ft

Mast tilt angle:

0 °

Noise at flyover, level:

0 dB EPNL

Noise at flyover, limit:

0 dB EPNL

Noise at takeoff, level:

0 dB EPNL

Noise at takeoff, limit:

0 dB EPNL

Noise at landing, level:

0 dB EPNL

Noise at landing, limit:

0 dB EPNL

Crew:

0

Max pax number:

0

Average price:

0 $
